Fully Automatic AAC Block Cutting Machine

Product Description

Functionality

The cutting machine is used to slice the pre-cured AAC cake (semi-solid mass) into blocks of required sizes with high precision. It performs vertical, horizontal, and end-face cutting in one integrated process.

Components and Features

1. Cutting Wires

   • High-strength wires are arranged vertically and horizontally to cut the AAC cake into blocks.
   • They ensure smooth and accurate cutting without damaging the edges.

2. Frame and Base

   • A robust steel frame supports the cutting mechanism.
   • The base ensures stability during operation and reduces vibrations for precision cutting.

3. Tilting Table

   • The pre-cured AAC cake is placed on a tilting table, which rotates or tilts to facilitate different cutting operations.

4. Vertical Cutting Section

   • Cuts the AAC cake vertically to define the length and width of the blocks.
   • Multiple wires are used to achieve consistent dimensions.

5. Horizontal Cutting Section

   • Cuts the AAC cake horizontally to determine the block height.
   • Ensures smooth surfaces for easy stacking and construction.

6. Groove and Tongue Cutting Tool (Optional)

   • Adds grooves or tongues to the blocks for better alignment during construction.

7. Automation System

   • Advanced control systems with PLC (Programmable Logic Controller) for automatic operation.
   • Sensors and software ensure precise measurements and minimal errors.

8. Conveyor System

   • Transfers the cut AAC blocks to the autoclaving section without manual handling, reducing breakage and improving efficiency.
